SP-150H

Roll upper pneumatic and lower mechanical drag
Axial shaft movement	22 mm
Vertical axes diameter	40 mm
Max. Saw Diameter	250 mm
Single tilted left and right head	-5º + 20º
Tilted Splitter Set	± 30º
Working capacity	150x80 mm
Feed Rate	10-60 m/min
Drag Power	5.5 hp
Left Head Axis	12.5 hp
Right Head Axis	12.5 hp
Upper horizontal axis Ø50 (option 40)	15 hp
Maximun working pressure	6 bar
Approx. Air Speed	30-35 m/seg
Approx. Amount of Air	3000 m³/h
Approx. Weight	1050 kg
Chrome Tables
Shape Jointer
Speed Variation Electronic Drag

Roll upper pneumatic and lower mechanical drag
Axial shaft movement
22 mm
Vertical axes diameter
40 mm
Max. Saw Diameter
250 mm
Single tilted left and right head
-5º + 20º
Tilted Splitter Set
± 30º
Working capacity
150x80 mm
Feed Rate
10-60 m/min
Drag Power
5.5 hp
Left Head Axis
12.5 hp
Right Head Axis
12.5 hp
Upper horizontal axis Ø50 (option 40)
15 hp
Maximun working pressure
6 bar
Approx. Air Speed
30-35 m/seg
Approx. Amount of Air
3000 m³/h
Approx. Weight
1050 kg
Chrome Tables
Shape Jointer
Speed Variation Electronic Drag
